軟板介紹與應用
技術能力
FPC 應用領域 (FPC Application)
一、靜態線材:當cable用,替代傳統排線. (Static Cable)
二、動態線材:有持續性擺動Cable. (Dynamic Cable)
三、PCB:Mount Component(零件)承載在 FPC上,具有 cable及PCB功能。
二、動態線材:有持續性擺動Cable. (Dynamic Cable)
三、PCB:Mount Component(零件)承載在 FPC上,具有 cable及PCB功能。
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/fpc-product-01.jpg)
智慧手持
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/fpc-product-02.jpg)
消費電子
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/fpc-product-03.jpg)
車用電子
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/fpc-product-04.jpg)
電池用線
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/fpc-product-05.jpg)
其他電子
特性
- 具高度曲撓性,可立體配線,依空間限制改變形狀。
- 耐高低溫,耐燃。
- 可折疊而不影響訊號傳遞功能,可防止靜電干擾。
- 化學變化穩定,安定性、可信賴度高。
- 利於相關產品之設計,可減少裝配工時及錯誤,並提高有關產品之使用壽命。
- 使應用產品體積縮小,重量大幅減輕,功能增加,成本降低。
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/tech-table.jpg)
製程一覽
製程設備
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/process-01.jpg)
物料裁剪
Material Cutting
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/process-02.jpg)
鑽孔
CNC
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/process-03.jpg)
鍍銅
PTH
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/process-04.jpg)
曝光
Exposuring
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/process-05.jpg)
蝕刻
DES
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/process-06.jpg)
AOI
雙面板流程
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-01.jpg)
貼合
Pre-Lamination
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-02.jpg)
壓合
Lamination
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-03.jpg)
鍍銅
PTH
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-04.jpg)
表面處理
Acid Dip(cleaning)
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-05.jpg)
金面處理
Surface Finished
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-06.jpg)
印刷
Screen Printng
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-07.jpg)
整板電測
O_S Test
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-08.jpg)
成型
Punch
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-09.jpg)
SMT
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-10.jpg)
加工
Assembly
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-11.jpg)
功能測
Function Test
![](https://www.cmi.com.tw/wp-content/uploads/2021/09/Double-Sided-Process-12.jpg)
檢驗
Inspection
